英国牛顿N4L PPA4500系列4530 4560 4510功率分析仪 功率计

英国牛顿N4L PPA4500系列4530 4560 4510功率分析仪 功率计

长沙泰克示波器 长沙泰克电源 长沙力科示波器 长沙力科电源 长沙安捷伦示波器 长沙力科电源 长沙安捷伦示波器 长沙安捷伦电源 长沙福禄克万用表 湖南福禄克万用表  高压探头 电流探头  湖南泰克示波器 湖南泰克电源  湖南力科示波器  湖南力科电源  湖南安捷伦示波器  湖南力科电源  湖南安捷伦示波器  湖南安捷伦电源  高压探头 电流探头

一、产品简介

The PPA4500 features high speed FPGA/DSP sampling techniques and N4L’s highly respected “Planar Shunt” Technology, the PPA4500 is the result of over 12 years of development. The PPA4500 replaces the outgoing PPA2500 and PPA2600 models, with improved accuracy, colour TFT, front USB port and faster processing. The PPA4500 is a significant leap forward in both accuracy and functionality. The PPA4500 exhibits the ability to measure fundamental frequencies up to 2MHz, as well as up to 100 Harmonics with the same 2MHz upper frequency limit. PWM Motor drive mode enables the engineer to rapidly **p the instrument to measure complex harmonically distorted waveforms, sophisticated signal processing algorithms facilitate high sample rate (2Ms/s) true wideband (2Mhz) analysis of PWM signals. The PPA4500 Utilises parallel digital filtering for fundamental frequency synchronisation without affecting the bandwidth of the measured data. All PPA4500 units are shipped with UKAS ISO17025 certification as standard, this is performed at N4L in the UK in our accredited ISO17025 Laboratory.

二、产品特点及详细参数

0.03% Basic accuracy	Frequency range DC and 10mHz to 2MHz
High precision internal shunts Superior accuracy to any external shunt	5 millidegree phase accuracy Necessary for low power factor applications
Up to 50 Arms (1000 Apk) & 1000 Vrms (3000 Vpk) direct input	Low current (10Arms), Standard (30Arms) and High current (50Arms) options
High speed sampling on all channels (2Ms/s)	True real time analysis with no measurement gap
1, 2 or 3 phase versions master – slave mode for 4, 5 or 6 phase	Real time Digital, Tabular, Graphic and Oscilloscope displays
Simple BNC connection of N4L shunts for high current applications	RS232, IEEE 488, USB, LAN, Torque, Speed and Extension ports
Up to 100 Harmonics	PWM Motor Drive Analysis Mode
Free PPALoG Datalogging Software available via download	Transformer Analysis Mode
